Call for Price

When hard flooring needs a bit of extra effort to get the best results, the Viper AS series is ready to make the difference, with dual-brush or orbital-deck models for applications ranging from heavy-duty scrubbing to surface-stripping.

Easy operation, high tank capacity, and the resource-efficiency needed to get the job done quickly and effectively, make the intuitive AS models an ideal match for cleaning programs that need consistent results across medium- and large-sized spaces.

    • Adjustable brush-pressure settings make it easy to handle all kinds and levels of dirt
    • Solution-flow management ensures optimal control of detergent dosage
    • Eco and Silent modes make it easy to clean over longer periods or in sound-sensitive areas
    • Easy access to solution tank, battery, and working components, with tool-free squeegee-blade removal
    • Convenient controls and LCD display for fast, effective training and operation


Selected ProductAS7690T
Product detailsProduct no: CM50000569-01
Solution tank (l)85
Recovery tank (l)90
Length1490 mm
Width with squeegee830 mm
Width without squeeegee730 mm
Height1020 mm
Pad/Brush Size330 mm x 2
Brush pressure (g/cm²)32 Kg
Solution flow0.9/1.5/2.2/3 Liters
Sound pressure level (dB(A))69 ± 3
Sound level - silent mode65 ± 3
Machine speed0 - 4.0 Km
Min. aisle turn (cm)155 cm
Battery compartment size (L x W x H)620 x 385 x 390 mm
Voltage (V)24 V
Cleaning productivity (max.)2640 m2/h
Gross weight (gvw) (kg)347 Kg
Shipping weight (kg)202 Kg
Packaging dimensions1620 x 810 x 1200 mm
Cleaning width (mm)
Adjustable brush pressurex
Click on-off brushx
Debris trayx
Display on machinex
Squeezable drain hose with flow controlx
One-Touch™ Buttonx
ECO modex
Traction drivex
