- Description
Description
| Model | HD623 | HD640 |
|---|---|---|
| Order N° | 497001 (Standard) 497002 (Premium) |
412001 (Standard) 412002 (Premium) |
| Voltage | 1 / 230 V / 50 Hz | 3 / 400-415 V / 50 Hz |
| Operating pressure | 30-160 bar / 3-16 MPa | 30-180 bar / 3-18 MPa |
| Max Pressure | 180 bar / 18 MPa | 200 bar / 20 MPa |
| Water Output | 300 – 600 l/h | 300 – 600 l/h |
| Hot water capacity | 30-98 °C | 30-98 °C |
| Nozzle size | 034 | 034 |
| Pump speed | 1400 rpm | 1400 rpm |
| Connected load | 3.1 kW / 15.1 A | 4.6 kW / 8.0 A |
| Electrical protection | 16 A slow-blowing | 3 x 16 A slow-blowing |
| Weight | 149 kg (Standard)/158 kg (Premium) | 157 kg (Standard)/167 kg (Premium) |
| Dimensions without hose drum (L x W x H) | 1070 x 735 x 1020 mm (Standard) 1070 x 735 x 1310 mm (Premium) |
1070 x 735 x 1020 mm (Standard) 1070 x 735 x 1310 mm (Premium) |
- Robust, corrosion-resistant, self-supporting device chassis
- Impact-Resistant device cover made of ABS
- Triplex piston pump with brass pump head, high-performance ceramic piston, stainless steel valves
- Leakage return
- Etronic I controls: Start-stop system with switch-off delay, total-switch-off after 20 min
- 2-motors system (independent of the direction of rotation) separately for high pressure pump and heating
- Unloader safety valve c/w infinitely variable pressure and quantity regulation
- 4 large rubber wheels for rough terrain, with a patented wheel brake 2-way
- Storage possibility for all accessories
- Integrated Diesel tank 25 l
- Integrated detergent tank 20 l
- Rotary ON/OFF switch, robust and lockable
- 7.5 m connection cable
- Removable ergonomic drawbar
